| Уникални функции |
Превъзходна производителност:
Солидна издръжливост:
- 6+1+1+1+1 Power Phase
- ASRock Intel® 4-Layer Memory POOL (Planes on Outer Layers) Technology
Свръхбърза връзка:
Актуализация на EZ:
- Програма за инсталиране на автоматични драйвери на ASRock
|
| Процесор |
- Supports Intel® Core™ Ultra Processors (Series 2) (LGA1851)
- Supports Intel® Hybrid Technology
- Supports Intel® Turbo Boost Max 3.0 Technology
- Supports Intel® Термално усилване на скоростта (TVB)
- Supports Intel® Адаптивна усилваща технология (ABT)
- Интегриран NPU за специално AI ускорение
|
| Чипсет |
Intel® H810 |
| Памет |
- Dual Channel DDR5 Memory Technology
- 2 x DDR5 DIMM Slots
- Supports DDR5 non-ECC, un-buffered memory up to 6400*
- Supports Clocked Unbuffered DIMM (CUDIMM)
- Max. capacity of system memory: 128GB*
- Supports Intel® Изключителен профил на паметта (XMP) 3.0x*
|
| BIOS |
256Mb AMI UEFI Legal BIOS with GUI support |
| Графика |
- Intel® Xe LPG Графична архитектура
- 1 x HDMI 2.1 TMDS/FRL 8G съвместим, supports HDR, HDCP 2.3 and max. резолюция up to 4K 120Hz
- 1 x Порт за дисплей 1.4 с DSC (компресиран), поддържа HDCP 2.3 и макс. резолюция до 8K 60Hz / 5K 120Hz
- 1 x D-Sub, supports max. резолюция up to Full HD (1920x1080) 60Hz
|
| Аудио |
7.1 CH HD Audio (Realtek ALC897 Audio Codec) |
| LAN |
- 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
- Dragon RTL8125BG
|
| Слотове |
CPU:
- 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*
Chipset:
- 1 x PCIe 4.0 x1 Slot (PCIE2)*
- 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
|
| Съхранение |
Chipset:
- 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
- 4 x SATA3 6.0 Gb/s Connectors
|
| USB |
Chipset:
- 1 x USB 3.2 Gen1 Type-C (Front)
- 4 x USB 3.2 Gen1 Type-A (2 Rear, 2 Front)
- 6 x USB 2.0 (4 Rear, 2 Front)
|
| Конектор |
- 1 x SPI TPM Header
- 1 x Power LED and Speaker Header
- 1 x RGB LED Header*
- 2 x Addressable LED Headers**
- 1 x CPU Fan Connector (4-pin) (Smart Fan Speed Control)***
- 1 x Chassis Fan Connector (4-pin) (Smart Fan Speed Control)****
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 1 x USB 2.0 Header (Supports 2 USB 2.0 ports)
- 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
- 1 x Front Panel Type C USB 3.2 Gen1 Header
|
| Заден панел с входове и изходи |
- 2 x Точки за закрепване на антената
- 1 x PS/2 Mouse/Keyboard Port
- 1 x D-Sub Port
- 1 x HDMI Port
- 1 x Порт за дисплей 1.4
- 2 x USB 3.2 Gen1 Ports
- 4 x USB 2.0 Ports
- 1 x RJ-45 LAN Port
- HD Audio Jacks: Line in / Front Speaker / Microphone
|
| Софтуер и UEFI |
Software
- ASRock Motherboard Utility (A-Tuning)
- ASRock Dragon 2.5G LAN Software
- ASRock Polychrome SYNC*
UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- Програма за инсталиране на автоматични драйвери на ASRock
- ASRock Мигновен Flash
|
| Аксесоари |
- 1 x I/O Shield
- 2 x SATA Data Cables
- 1 x Screw for M.2 Socket
|
| Форм фактор |
Micro ATX Form Factor: 8.66-in x 7.6-in, 22.0 cm x 19.3 cm |
| OC |
Microsoft® Windows® 11 64-bit |
| Сертификати |
- FCC, CE
- ErP/EuP ready (ErP/EuP ready power supply is required)
|
