Essentials
CPU Specifications
| Total Cores |
14 |
| # of Performance-cores |
6 |
| # of Efficient-cores |
8 |
| Total Threads |
20 |
| Max Turbo Frequency |
4.80 GHz |
| Performance-core Max Turbo Frequency |
4.80 GHz |
| Efficient-core Max Turbo Frequency |
3.50 GHz |
| Performance-core Base Frequency |
2.50 GHz |
| Efficient-core Base Frequency |
1.80 GHz |
| Cache |
24 MB Intel® Smart Cache |
| Total L2 Cache |
11.5 MB |
| Processor Base Power |
65 W |
| Maximum Turbo Power |
154 W |
Memory Specifications
| Max Memory Size (dependent on memory type) |
128 GB |
| Memory Types |
Up to DDR5 Up to DDR4 3200 MT/s |
| Max # of Memory Channels |
2 |
| Max Memory Bandwidth |
76.8 GB/s |
| ECC Memory Supported |
Yes |
Processor Graphics
| Processor Graphics |
Intel® UHD Graphics 770 |
| Graphics Base Frequency |
300 MHz |
| Graphics Max Dynamic Frequency |
1.55 GHz |
| Graphics Output |
eDP 1.4b, DP 1.4a, HDMI 2.1 |
| Execution Units |
32 |
| Max Resolution (HDMI) |
4096 x 2160 @ 60Hz |
| Max Resolution (DP) |
7680 x 4320 @ 60Hz |
| Max Resolution (eDP - Integrated Flat Panel) |
5120 x 3200 @ 120Hz |
| DirectX* Support |
12 |
| OpenGL* Support |
4.5 |
| OpenCL* Support |
3.0 |
| Multi-Format Codec Engines |
2 |
| Intel® Quick Sync Video |
Yes |
| Intel® Clear Video HD Technology |
Yes |
| # of Displays Supported |
4 |
| Device ID |
0x4680 |
Expansion Options
| Direct Media Interface (DMI) Revision |
4.0 |
| Max # of DMI Lanes |
8 |
| Scalability |
1S Only |
| PCI Express Revision |
5.0 and 4.0 |
| PCI Express Configurations |
Up to 1x16+4, 2x8+4 |
| Max # of PCI Express Lanes |
20 |
Гаранция: 36 месеца
Официална страница на продукта:
https://ark.intel.com/content/www/us/en/ark/products/230580/intel-core-i513500-processor-24m-cache-up-to-4-80-ghz.html
